5040A Active Subwoofer


The Genelec 5040B is an extremely compact and accurate active subwoofer designed to complement up to five 6010B monitors.

Reaching down to 35 Hz and perfectly matched with 6010B's monitors, the 5040B conveniently features a remote volume control allowing adjustment of the entire sound system as well as versatile acoustic controls for perfect room integration. The 5040A features Genelec Intelligent Signal Sensing (ISS™) circuitry which switches the monitor to standby when no audio input is detected (ErP 2013 Directive).

The 5040A is the ideal source of bass reproduction for small reproduction systems where space is at a premium.









5040A 1 front view pm
maximum sound pressure level 98 dB
frequency response Main 35 - 85 Hz (± 3 dB)
LFE 35 - 120 Hz (± 3 dB)
phase correcting 0 to -270° (90° steps)
driver dimension 6.5 in Active
amplifier power 40 W
dimensions H x D 251 x 305 mm
weight 6.3 Kg (13.9 lb)
connectors 5.1 RCA analog in
1 x 3.5 mm stereo jack in
5 x RCA analog out

5040A 9b bottom view pm
TEC Winner09  The 5040A is a TEC (Technical Excellence & Creativity) 2009 Award winner in the category Studio Monitor Technology.
For high resolution photos please visit: flickr.com/genelec
The 5040A matches the 6010A active loudspeaker in stereo and up to 5.1-channel surround systems.
It can also be used with model 8020B in stereo applications.



5040A & 6010A (Stereo)
5040A with two 6010A

h-line

5040A & 8020B (stereo)
5040A with two 8020B
v-line 5040A & 6010A (5.1)
5040A with five 6010A
