8330A

SAM™ Studio Monitor

Combining precision, adaptability and a small footprint, the 8330A offers colour-free performance and powerful room compensation features.

Smart Active Monitoring (SAM™) and GLM™ calibration technology

Directivity Control Waveguide (DCW™) Technology


SPL

104 dB

Frequency Response

45 Hz - 23 kHz (-6 dB)

Dimensions

H 299 x W 189 x D 178 mm, with Iso-Pod™ (view in inches)

The professional’s choice

The choice of demanding professionals for whom power and flexibility go hand-in-hand, the 8330A offers a little more SPL and LF extension than its smaller 8320A sibling. Providing transparent and truthful reproduction, the 8330A’s wide uncoloured sweet spot means you are always in a position to make accurate, reliable mix decisions.

Jarkko Ripsomaa Studio

Truly optimised monitoring

As a Smart Active Monitor, the 8330A integrates closely with our GLM software via which it can be configured and calibrated for your listening environment, compensating for detrimental room influences to create a truly optimised monitoring solution from mono to immersive. So if you need to work in challenging acoustic spaces, the 8330A is your compact but clever monitoring companion.

Genelec

8330A SAM™ Studio Monitor Dark Grey

8330A SAM™ Studio Monitor White

8330A SAM™ Studio Monitor RAW

Color options:
Package contains:

1 x 8330A monitor
1 x mains cable 1,8 m
1 x RJ45 cable 5 m
1 x operating manual

Warranty:
2 years parts-and-labour (extended to 5 years with free registration).

GLM Calibration:
Requires free GLM software and either our 9320A SAM™ Reference Controller or GLM Calibration Kit device (both sold separately) for calibration.

Genelec

8330A SAM™ Studio Monitor Dark Grey

8330A SAM™ Studio Monitor White

8330A SAM™ Studio Monitor RAW

Color options:

Technical Specifications

SPL

104 dB

Amplifier Power

50 W Bass (Class D) + 50 W Treble (Class D)

Frequency Response

45 Hz - 23 kHz ("-6 dB")

Accuracy of Frequency Response

± 1.5 dB (58 Hz - 20 kHz)

Driver Dimensions

130 mm Bass + 19 mm Treble (view in inches)

Dimensions

H 299 x W 189 x D 178 mm, with Iso-Pod™ (view in inches)

Weight

5.1 kg / 11.2 lb

Connections

1 x XLR Analog Input

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control


Key Technologies

Smart Active Monitoring (SAM™) and GLM™ calibration technology

Directivity Control Waveguide (DCW™) Technology

Intelligent Signal Sensing (ISS™) Technology

Active Crossovers

Iso-Pod™ Stand

Optimised Amplifiers

Protection Circuitry

Reflex Port Design

Versatile Mountings

Minimum Diffraction Enclosure (MDE™) Technology


References

Genelec UNIO Explained | How the ecosystem offers seamless in-room and personal headphone monitoring

Jonna Tervomaa interview - The Art of Creating in Your Space

Using GLM | Walkthrough

Using GLM | The foundations

Using GLM | Controlling GLM with MIDI

Using GLM | GRADE Room Acoustic Report

Using GLM | Calibration Group IDs

Using GLM | Accounts and product registration

Using GLM | The technical details


Find Your Dealer

Type in your city to find your nearest Genelec dealer

Filters
X Filters
All
Studio monitors
Home speakers
AV Installation
Technical Service
Showroom
Experience Centre
SAM Certified
Smart IP Certified
Selected country

Documentation

FAQ

There are several improvements in the new 83xx products. The capability to adapt to the room acoustics has been improved greatly, and, for example, 8320 and 8330 products provide four to five times higher number of tools for room response compensation compared to the 82xx products. The delay alignment capability has been expanded from about 80 ms to about 200 ms in 83xx. 83xx have been time-equalized internally to have a constant input-to-output delay above 400 Hz. 83xx products can level align by 60 dB.

All 83xx and 73xx products support distributed bass management, enabling the audio signal to be passed unmodified from the source and through the subwoofer into the monitors. 73xx subwoofers support a multichannel analogue audio signal and stereo AES/EBU digital audio signal.
