If you love the compact format of the 8010 and 8020 models but demand higher SPL and more bass extension, meet the 8030C.
8030C Studio Monitor
Directivity Control Waveguide (DCW™) Technology
47 Hz - 25 kHz (-6dB)
Welcome to the sweet spot
A consistent best-seller, the 8030C sits in the perfect sweet spot of big monitor performance and small footprint. It offers precise imaging and staggering detail, but can go louder and lower than its smaller siblings – making it the perfect choice for slightly larger spaces.
Mixes that translate
The trademark rounded cabinet design of the 8030C delivers uncoloured reference performance both on and off axis, and rear panel room compensation switches let you optimise the 8030C for your individual room acoustics. All this helps you produce mixes that translate beautifully to other rooms and systems.
8030C Studio Monitor Dark Grey
8030C Studio Monitor White
8030C Studio Monitor RAW
1 x 8030C monitor
1 x mains cable 1,8 m
1 x operating manual
8030C Studio Monitor
Genelec 8000 Series was Awarded a MIPA Award 2005 for Best Nearfield Studio Monitors
Genelec Oy: the world leader in active studio monitor speakers, was awarded a prestigious MIPA (Music Industry Press Award) for Best Studio Monitor (Nearfield) for its latest 8000 series of monitors at the Musikmesse, last month.
This award has become the 'Grammy' of the Musical Instrument and Pro Audio industries. Fifty-eight music press magazine from all over the globe cast their vote to make Genelec winner of the category.
Genelec 8000 series studio monitors
The 8000 Series of near-field, two-way systems took two years to develop. It features a new approach to enclosure design, driver technology and active electronics to further reduce distortion and provide an outstanding performance.
All three models in the 8000 series feature die-cast aluminium, minimum diffraction enclosures (MDE™) which have large internal volumes, softly curved edges and outstanding strength to help reduce linear and non-linear distortion. They also incorporate Advanced Directivity Controlled Waveguide (DCW™) to provide extremely accurate control of the speaker's directivity.
8030A studio monitor
The 8030A has a 5 inch bass driver and 3/4 inch tweeter. The free field frequency response is 55Hz to 21kHz, Peak SPL per pair is 108dB driven by a pair of 40 watt amplifiers.
8040A studio monitor
The 8040A has a 6 1/2 inch bass driver and 3/4 inch tweeter. The free field frequency response is 45Hz to 21kHz. Peak SPL per pair is 115dB driven by a pair of 90 watt amplifiers.
8050A studio monitor
The largest model the 8050A features an 8 inch bass driver and 1inch tweeter. The free field frequency response is 35Hz to 21 kHz. Peak SPL is 120dB and bass and treble amplification is 150 and 120 watts respectively.
50 W Bass (Class D) + 50 W Treble (Class D)
47 Hz - 25 kHz ("-6 dB")
Accuracy of Frequency Response
± 2 dB (54 Hz - 20 kHz)
5 kg / 11.0 lb
1 x XLR Analog Input
8030C Studio Monitor
54 Hz - 20 kHz (± 2 dB)
Low cutoff -6dB
High cutoff -6dB
Peak SPL Maximum peak acoustic output per pair at 1 m distance with music material.
Maximum peak acoustic output per pair at 1 m distance with music material.
Short term max SPL Maximum short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz at 1 m.
Maximum short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz at 1 m.
Long term max SPL Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by driver unit protection circuit) at 1 m.
Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by driver unit protection circuit) at 1 m.
Self-generated noise Self generated noise level in free field at 1 m on axis (A-weighted).
Self generated noise level in free field at 1 m on axis (A-weighted).
5 kg (11.0 lb)
Height with Iso-Pod
Die cast aluminium
> 100 Hz ≤0.5 %
50 W Class D
50 W Class D
100-240 VAC 50/60Hz
Signal processing section
Input Analog signal input connector XLR female, balanced 10 kOhm.
Analog signal input connector XLR female, balanced 10 kOhm.
For even more technical details please see product operating manual.
Directivity Control Waveguide (DCW™) Technology
Intelligent Signal Sensing (ISS™) Technology
Minimum Diffraction Enclosure (MDE™) Technology
Reflex Port Design
Room Response Compensation
Active crossover operating at low signal levels.
Audio electronic crossovers allow to split the audio signal into separate frequency bands that can be separately routed to individual power amplifiers which then are connected to specific transducers optimized for a particular frequency band.
Active crossovers come in both digital and analogue varieties. Genelec digital active crossovers include additional signal processing, such as driver protection, delay, and equalization.
Genelec analogue active crossover filters contain electronic components that are operated at low signal levels suitable for power amplifier inputs. This is in contrast to passive crossovers that operate at the high signal levels of the power amplifier's outputs, having to handle high currents and in some cases high voltages.
In a typical 2-way system the active crossover needs two power amplifiers — one for the woofer and one for the tweeter.
The active crossover design offers multiple benefits:
- The frequency response becomes independent of any dynamic changes in the driver's electrical characteristics or the drive level.
- There is an increased flexibility and precision to adjust and fine tune each output frequency response for the specific drivers used.
- Each driver has its own signal processing and power amplifier. This isolates each driver from the drive signals handled by the other drivers, reducing inter-modulation distortion and overdriving problems.
- The ability to compensate for sensitivity variations between drivers.
- The possibility to compensate for the frequency and phase response anomalies associated with a driver’s characteristics within the intended pass-band.
- The flat frequency response of a high-quality active loudspeaker is a result of the combined effect of the crossover filter response, power amplifier responses and driver responses in a loudspeaker enclosure.
Using the active approach enables frequency response adjustments and optimization of the full loudspeaker system, placed in various room environments, without expensive external equalizers. The end result is a simpler, more reliable, efficient, consistent and precise active loudspeaker system.
Directivity Control Waveguide (DCW™) for flat on- and off-axis response.
A revolutionary approach was taken by Genelec in 1983 with the development of its Directivity Control Waveguide (DCW™) used at the time in an egg-shaped enclosure. The Genelec DCW technology developed and refined over more than 30 years greatly improves the performance of direct radiating multi-way monitors.
The DCW technology shapes the emitted wavefront in a controlled way, allowing predictable tailoring of the directivity (dispersion) pattern. To make the directivity uniform and smooth, the goal is to limit the radiation angle so that the stray radiation is reduced. It results in excellent flatness of the overall frequency response as well as uniform power response. This advanced DCW technology minimizes early reflections and provides a wide and controlled listening area achieving accurate sound reproduction on- and off-axis.
Minimized early reflections and controlled, constant directivity have another important advantage: the frequency balance of the room reverberation field is essentially the same as the direct field from the monitors. As a consequence, the monitoring system's performance is less dependent on room acoustic characteristics.
Sound image width and depth, critical components in any listening environment, are important not only for on-axis listening, but also off-axis. This accommodates not only the engineer doing his or her job, but also others in the listening field, as is so often the case in large control rooms.
DCW™ Technology key benefits:
- Flat on- and off-axis response for wider usable listening area
- Increased direct-to-reflected sound ratio for reduced control room coloration
- Improved stereo and sound stage imaging
- Increased drive unit sensitivity up to 6 dB
- Increased system maximum sound pressure level capacity
- Decreased drive unit distortion
- Reduced cabinet edge diffraction
- Reduced complete system distortion
Intelligent Signal Sensing (ISS™) for power consumption reduction in stand-by mode.
Introduced early 2013, Genelec’s Intelligent Signal-Sensing technology has been developed to meet with both European Union ErP Directives and the company’s own wider sustainability commitments.
The Intelligent Signal Sensing, ISS™ circuitry tracks the signal input of the loudspeaker and detects if it is in use. If the ISS circuit does not find any audio on the input for a period of time, it sets the loudspeaker to a low-power sleep state and the loudspeaker will consume less than 0.5 watts. When an input signal is detected, the loudspeaker immediately turns itself on. Basically, the loudspeaker system will start saving power as soon as work is interrupted.
Additionally an ‘ISS Disable’ switch is located on each product’s back plate next to the other room response controls. First, when the mains power switch of the loudspeaker is set to “ON”, the ISS™ auto-start function (low-power sleep state on/off) of the loudspeaker is active.
If this function is not desired, the ISS™ function can be disabled by setting the “ISS Disable” switch on the back panel to “ON” position. In this mode, the monitor is only powered on and off using the mains power switch.
Note that the mains power switch will always turn the monitor off completely.
Vibration decoupling Iso-Pod™ stand improves sound image definition.
Although it is advisable to use sturdy and stable floor stands together with free-standing loudspeakers, a very common solution is to place loudspeakers directly on a table or on a console meter bridge.
This causes several detrimental side effects. Aiming of the loudspeaker axis towards the listener is rarely implemented, also, unwanted mechanical vibration do propagate from the loudspeaker to the mounting surface, and first order reflection on the work surface causes comb filtering and hence ripples in the frequency response.
To solve these very common problems Genelec developed an efficient and very practical solution. We designed a loudspeaker stand called Iso-Pod™ - Isolation Positioner/Decoupler that is attached to the aluminium enclosure. It has four shallow feet and it is made from special lossy rubber-like material. It is firmly attached to the enclosure so that it can be slid along the curved bottom or side surface to allow for a ±15° tilt of the loudspeaker.
The loudspeakers’ acoustical axis can then be pointed precisely towards the listener by adjusting the enclosure’s inclination with the Iso-Pod. The vibration isolation and damping properties reduce midrange coloration caused by unwanted vibration transmitted to supporting surfaces.
This innovative solution is an integral part of Genelec loudspeaker design and provides clear benefits in usability and sound quality.
Minimum Diffraction Enclosure (MDE™) for uncoloured sound reproduction.
A common problem with standard free-standing loudspeakers is that the front baffle discontinuities cause diffractions and the loudspeaker sharp corners act as secondary sources through reflections.
In order to improve the flatness of the frequency response and the power response of free standing loudspeaker systems, Genelec have designed a highly innovative enclosure optimized to match the properties of the monitor drivers, featuring rounded edges, and gently curved front and sides. In addition to achieving an unsurpassed flatness of the frequency response, the enclosure having minimum diffractions yields superb sound stage imaging qualities.
To achieve such a smooth and elegantly curved cabinet surface and to reduce the outer dimensions of the enclosure, maximising at the same time the internal volume for improved low frequency efficiency, we designed a cabinet made off die-cast aluminium. Aluminium is lightweight, stiff and very easy to damp to yield a “dead” structure. The cabinet walls can be made fairly thin, providing at the same time good EMC shielding and excellent heat sink for the power amplifiers. Die-casting is made in two parts, front and rear, and they are easy to separate for potential servicing needs.
The DCW waveguide has been integrated in the MDE aluminium enclosure to provide improved control of the loudspeaker’s directivity. Basically, the low frequency limit for constant directivity is determined by the size of the waveguide, so the larger the surface the better the control. With a very controlled off-axis radiation, the listening window becomes consistent, which is of utmost importance with multi-channel audio monitoring. Controlled directivity also reduces possible first order reflections on surfaces near the loudspeaker, helping to provide consistent audio reproduction in different acoustical environments. In fact, the entire front baffle is gently curved and the acoustically transparent grilles are part of the outer cabinet aesthetics, blending perfectly with the various other curved surfaces.
Each transducer is driven by its own optimized amplifier.
Audio electronic crossovers allow to split the audio signal into separate frequency bands that can be separately routed to individual power amplifiers which then are connected to specific transducers optimized for a particular frequency band.
In a typical 2-way loudspeaker system, the active crossover needs two power amplifiers — one for the woofer and one for the tweeter. The power amplifiers are connected directly to the drivers of an active loudspeaker, resulting in the power amplifier’s load becoming much simpler and well known. Each driver-specific power amplifier has only a limited frequency range to amplify (the power amplifier is placed after the active crossover) and this adds to the ease of design.
The active design principle offers multiple benefits:
- The power amplifiers are directly connected to the speaker drivers, maximizing the control exerted by the power amplifier’s damping on the driver’s voice coil, reducing the consequences of dynamic changes in the driver electrical characteristics. This may improve the transient response of the system.
- There is a reduction in the power amplifier output requirement. With no energy lost in the passive crossover filter components, the amplifier power output requirements are reduced considerably (by up to 1/2 in some cases) without any reduction in the acoustic power output of the loudspeaker system. This can reduce costs and increase audio quality and system reliability.
- No loss between amplifier and driver units results in maximum acoustic efficiency
- Active technology can achieve superior sound output vs. size vs. low frequency cut-off performance
- All loudspeakers are delivered as a factory aligned system (amplifiers, crossover electronics and enclosure-driver systems)
Sophisticated drive unit protection circuitry for safe operation.
When working in critical audio production environments it is essential that monitoring systems remain reliable and functional at all times. One of the main reasons behind Genelec’s excellent success in broadcasting environments is the reliability of our products and a key element behind the reliability is the internal protection circuitry found in all products since 1978.
The protection circuitry prevents driver failures by detecting signal levels, and in case of sudden peaks or constantly too high levels, taking the signal level down automatically. Of course this feature does not affect the sound quality in any way when working within the specifications of the loudspeaker, but only prevents inadequate input signals from breaking the loudspeaker.
Protection circuitry features and benefits:
- Reduces the output level when required, (e.g. when driver voice coil temperature reaches the safe limit) which highly improves the system reliability
- Appropriate protection circuitry design in every loudspeaker and subwoofer enables to maximise system output sound level.
Advanced reflex port design for extended low frequency response.
Genelec’s choice for vented, or reflex, enclosures dates back to the S30 model, the first Genelec product from 1978. Port performance has been improved and refined over the years with the aim to increase the woofer’s low frequency extension and sound pressure level capability to provide outstanding bass articulation and definition.
Both driver and vent contribute to the total radiation of a reflex enclosure. Most radiation comes from the driver, but at the vent-enclosure resonant frequency the driver displacement amplitude is small and most of the radiation comes out of the vent.
To minimize the air speed in the tube, the cross sectional area of the vent should be large. This in turn means that the vent tube has to be long which presents quite a design challenge.
The long, curved tube maximizes airflow so deep bass can be reproduced without compression. The reflex tube terminates with a wide flare located on the rear of the enclosure for obvious reasons, minimizing port noises and providing excellent bass articulation.
The curvature of the tube has also been carefully designed to minimize any audible noise, compression or distortion. The inner end of the tube has proper resistive termination to minimize once again audible chuffing noise and air turbulence.
Proper reflex port design allows also to significantly reduce the woofer’s displacement, improving the linear low frequency output capacity.
Precise room response compensation for optimizing in-room performance.
The interaction between room acoustic and loudspeaker radiation is complex. Each room changes somewhat the monitor’s response in a unique way, e.g. reflective vs. damped rooms, or placement against a wall vs. on a stand away from the walls.
All Genelec loudspeaker systems feature room response adjustments to compensate for the room influences and retrieve a flat frequency response at the listening position.
Genelec analogue loudspeaker systems provide versatile Room Response Controls. They include (depending on models):
- Bass Roll-Off and Bass Tilt
- Treble Tilt and Treble Roll-Off
- Bass Level
- Midrange Level
- Treble Level
- Desktop Control
At low frequencies two main controls are provided. The Bass Tilt control, which acts as a shelving filter together with the Bass Roll-off control allowing you to optimize the low and very low frequency response of the system in different installations. Bass, midrange and treble level controls are provided in large systems. These controls allow to optimize the relative balance between the various pass bands.
The operating manual and datasheet of each loudspeaker contains a list of preferred room response control settings for different installations. These have been specified out of long practical experience and measurements of various kind of typical acoustic environments.
Smart Active Monitor (SAM™) Systems
Genelec SAM Systems offer a comprehensive, solution-oriented, intelligently networked product range which all feature Genelec Loudspeaker Manager (GLM™) software and its automatic calibration system called AutoCal™.
Genelec AutoCal provides the industry’s first integrated process for complete automated measurement, analysis, and adjustment of every monitor on the GLM control network. The system measures the response in the listening area and applies relevant compensation in the low and low-mid frequencies to minimise the detrimental room acoustic anomalies as well as the differences between various listening positions. AutoCal also aligns relative levels, time-of-flight, as well as adjusts correct crossover phase (called AutoPhase) for all subwoofers on the network.
The Acoustic Response Editor provides accurate graphical display of the measured response, filter compensation and the resulting system response for each monitor, with full manual control of acoustic settings.
Versatile mounting options for all installation needs.
In addition to perfect acoustical design and advanced tailoring options to optimize the loudspeaker’s behaviour to the room environment, Genelec loudspeakers offer a variety of mounting options for easy installation in different applications.
Our wide range of accessories and fixed mounting points on the back of our aluminium enclosure products offer solutions to all common installation situations. M6 support points have been integrated in the die-cast enclosure for wall and ceiling mounts.
Some models also feature a 3/8” thread at the bottom of the enclosure to fit a robust microphone stand. Other larger and heavier models feature M10 fixing points. Special floor stand plates have been designed in order to fit the Iso-Pod stand that is part of our product design.
With these features our loudspeakers have found their way to a variety of applications beyond the professional audio and studio world, for example in commercial and AV installation projects as well as in home environments all around the world.
G Livelab – The future of live music in Tampere relies on Genelec
Genelec Smart IP opens up ‘world of possibilities’ for new G Livelab live venue.
Pressure Cooker builds up steam with Genelec
Music and sound design house Pressure Cooker in Cape Town have standardised on Genelec throughout their new facility.
In the wake of the unmitigated success that is G Livelab Helsinki, the Finnish Musicians’ Union has opened a brand new – and bigger – venue in the vibrant city of Tampere, some 200km north of the Finnish capital. The same team was deployed to realise the Tampere project which is built according to the same ‘music first’ philosophy as Helsinki. The result is an extraordinary live music experience based on quality programming, modern design, and state-of-the-art Genelec audio systems including the ground-breaking new 4430 Smart IP loudspeaker.
Housed in a striking red brick building which was formerly the boiler house of the Frenckell paper mill in the heart of the city, the venue hosts up to 250 people and offers a hugely varied programme including jazz, folk, world music, pop/rock, chamber music, electronic music and more. Akukon Oy designed the acoustics, electroacoustics, lighting, sound, video, communication systems and basic IT structure as well as the rigging systems, as they did for Helsinki, and leading Nordic AV integrator, Bright – another key member of the Helsinki team – brought Akukon’s vision to life.
“Genelec was already a tried and tested solution with the first G Livelab project in Helsinki which has had great reviews,” explains Bright’s Head of Installation, Santtu Sipilä. “People really liked what we achieved in Helsinki, so it was an obvious decision to equip the Tampere club with Genelecs as well.”
The biggest difference between the two venues is the space – Tampere is much bigger with significantly higher ceilings. Although this posed certain challenges in terms of acoustic treatment, it also allowed greater freedom for the audio design.
The second notable difference is the use of Genelec’s 4430 Smart IP loudspeakers which weren’t available at the time of the Helsinki installation.
“We definitely wanted the new 4430s for easier cabling and added control; it’s opened up a world of possibilities for us,” admits Sipilä. “We have a fully networked system running on Dante – this includes the big loudspeakers used for the main PA – and any of the 4430s can take any signal from anywhere. This means that we can use the same loudspeakers for virtual acoustics, surround sound, background music, delays… the possibilities are endless, and it’s enabled us to considerably reduce the total amount of loudspeakers required in order to achieve what we wanted. We are able to make art with loudspeakers and we are not limited in any way in terms of how we can use the system.”
Tapio Ilomäki, the project manager for Akukon, agrees: “Our primary objective was the same as for Helsinki: to deliver a high-quality system with high musicality that serves the performer best. However, the versatility of systems and spaces was a key element of the design; modern venues need to be multi-purpose and they have to be able to facilitate these changes as quickly and easily as possible, for optimum functionality and quick return on investment. The use of the 4430s plays an important role at this level as well as offering extremely musical sound with very low distortion.”
The ability to have everything delivered over just a single cable is every installer’s dream.
Sipilä is also extremely impressed with the PoE (Power over Ethernet) capabilities of the 4430s. “We were really surprised by the SPLs and sound quality from this size of loudspeaker over PoE. We honestly didn’t think it was possible, so yes, we’re very impressed. The ability to have everything delivered over just a single cable is every installer’s dream, so I think that Genelec’s Smart IP range will be figuring in a great many of our future designs!”
In addition to the 4430s, the main PA system comprises a pair of 1236 SAM studio monitors, the flagship of the Genelec range, seventeen S360s for surround and delay, a pair of 1238s as the first delay line, and finally a flown sub array of nine 7380 subwoofers. “We didn’t have either the height or the space to include subs in Helsinki, so this is a welcome addition in Tampere which gives us some extra headroom in the system and helps add body and fullness to the sound,” continues Sipilä.
When you come here to listen to live music, it will most likely sound even better than it did on the record.
Renowned Finnish singer/songwriter, Markus Nordenstreng of Tuomo & Markus and the Latebirds considers G Livelab as his favourite venue for intimate performances. “Some of the best music I have ever heard has been live, but sound quality is often let down by the venue, either through bad acoustic treatment or a sub-par sound system – or both. What you have here at G Livelab is just the opposite end of the scale – for me it’s the ultimate live sound experience. When you come here to listen to live music, it will most likely sound even better than it did on the record – you can hear things you never heard before. It would be a great service to mankind if there was a G Livelab in every city around the world!”
The final word goes to Annamaija Saarela, CEO of G Livelab Tampere: “G Livelab isn’t just about the technology or the programming – it’s about the whole experience of enjoying live music, and I’m proud to say that in bringing together the best of everything and everyone involved, we have achieved a result that is even greater than the sum of the parts. We’ve had nothing but positive feedback since we opened, both from the public and musicians alike.”
Pressure Cooker Studios, a respected music and sound design house specialising in music production for film, television and advertisements, has recently moved into their new purpose-built studio facility in the centre of Cape Town, designed by world-renowned studio designer Martin Pilchner of Pilchner Schoustal International Inc. Genelec is at the heart of this new facility, with its local distributor, TruFi, supplying monitors for all of its recording studio spaces.
From humble beginnings in the basement of a house 10 years ago to a 355 square metre studio space, the new facility is exactly how the Pressure Cooker team had envisioned it from the outset, and features two main control rooms which sandwich a main studio proper, a 7.1 post theatre with adjacent ADR booth, five writing rooms, an independent isolation booth, reception, lounge and common spaces. James Matthes, Co-Founder and CEO of Pressure Cooker Studios notes: “We wanted to make our space as comfortable, but also as technologically advanced as possible – we spend so much time here, so it definitely had to feel lived in, making it a homely but premium space.”
Helping the Pressure Cooker team achieve this feat was Genelec’s GLM software. “The GLM system is fantastic in that it assists with all the relevant calibration of any one of the monitors within the array in terms of EQ and phase alignment,” notes Neil Leachman, Final Mix Engineer at Pressure Cooker. “After the system is aligned and EQ'd I spent a small amount of time just setting up levels for the individual outputs to align properly to the recommended levels for cinema monitoring for surround and R128 compliance. But the GLM system is invaluable in the setup.”
Pressure Cooker has been using Genelec stereo and surround sound monitoring systems since the company was founded, and this trend continues in the new facility. “Every room in the facility has Genelec!,” smiles Matthes “From buying my first pair over nine years ago, I have never looked back – each monitor is fantastic. The sound produced is so clean, natural and unadulterated – nothing colours it, and I just love that.”
Each room in the new facility has utilised Genelec monitors in one way or another; Matthes has a pair of 8040 nearfields in his writing room, there are three 1238A three-ways fulfilling the LCR role behind the screen in the 7.1 theatre, with two 7380A 15-inch subwoofers and 8040s as surrounds - while the smaller rooms all have 8030 nearfields. “We chose a uniform approach with Genelec because we wanted to be able to move from room to room and feel comfortable from the moment we hit play.” Matthes continues.
“For example, if I go from a writing session to the composition suite, or start doing a mix with a client in the theatre – my ears aren’t going to trick me. I find with Genelec, you don’t need any other reference monitor at any point, since they just naturally translate very well.”
The first true test for Pressure Cooker’s new facility was the film ‘This is not a burial, it is a resurrection’ that was premiered at this year’s Venice Film Festival. “This was the first film we mixed using our Genelec system and particularly for the international market, it converted amazingly,” says Matthes. “The film’s producer told us how clear and brilliant the sound was, which makes me very confident in the set-up we have, and confirms that our decision to choose Genelec for the whole facility was the right one.”
The Finnish Sports Museum housed at the Olympic Stadium in Helsinki has recently reopened to the public with a completely revitalised permanent exhibition after extensive renovations closed the venue for five years. The new exhibitions celebrate Finnish sport using the best of what modern technology has to offer, including a state-of-the-art Genelec Smart IP audio solution. All audio, video and control technology was supplied by AV integration specialists Studiotec Oy, with AV and sound design by building services engineering experts, Granlund Oy.
Granlund’s Aki Päivärinne and Timo Muurinen were responsible for the AV design. “Our aim was to put the visitor in the middle of the action, to make them feel as if they are really there,” says Päivärinne. “It’s hard to think of any sport where sound is not a crucial part of the experience. Sounds from various sports are accompanied with occasional musical layers specially composed for the exhibition, and UX (User Experience) sounds. The sound design was realised using object-based sound design tools – immersive audio is the key to making the experience as complete as possible.”
The Smart IP speakers are definitely the most important element of
the audio solution.
Päivärinne specified Genelec’s Smart IP range of loudspeakers for most of the sound design, as they met all of his criteria for quality and particularly for ease of deployment. “The ability to use the museum’s existing CAT cabling infrastructure for both power and audio signal transport simplified the system design and installation enormously, as we didn’t have to worry about any analogue cables – everything just sits on the existing network.”
Project manager Pauli Lamsijärvi from Studiotec agrees. “The Smart IP speakers are definitely the most important element of the audio solution and certainly made life easier for us in terms of installation,” he notes. “They operate on the Dante network which carries both audio and control signals. It even delivers power to the speakers via PoE, which is something of a revolution in the audio world. The audio quality is what we’re used to hearing from Genelec – in other words, world class – so we’re very pleased with the results.”
The result is a fully immersive experience that truly brings the action to life for the visitor.
One of the largest exhibitions is Finnish sporting heroes across the ages. Visitors are treated to a massive video projection by Finnish visual artist, Janne Ahola, combined with a 10-channel immersive sound design using Genelec 4430s that places sound objects in space relative to what is happening on the screen. The result is a fully immersive experience that truly brings the action to life for the visitor.
Another exhibition is dedicated to winter sports. “Winter sports are important for us Finns, so this was another area where we wanted to make the experience as real as possible,” says Päivärinne. “Once again, we have a multichannel sound system using eight 4430 Smart IP loudspeakers in a stretched diamond layout that works with a short movie projected onto a 98” LED screen. Visitors will find themselves amongst children playing in the snow, skating on a frozen lake or even swimming in the lake – since Finns are a bit mad like that! Another part of the winter sports section takes us up onto the slopes with skiers and snowboarders. There is even an authentic double chair lift from 1965 with a huge screen behind it to reinforce the impression of being out on the slopes. Here I used four 4430s.”
The final area to use a Smart IP solution is the water sports exhibition which is brought to life using a 4-channel immersive sound system with four 4430s. Visitors experience the thrills of scuba diving below the waves to sailing above them, before being hurled into a canoe to negotiate the rapids.
Where the requirement was for stereo rather than immersive sound, Päivärinne opted for Genelec 8010 and 8030 loudspeakers, as the media players are located close to the loudspeakers. The larger installations with immersive multichannel sound designs all use Genelec Smart IP loudspeakers run from dedicated media servers capable of outputting Dante signals.
All of the museum's AV equipment is controlled from a single touch screen linked to the control system. All the projectors and dozens of monitors can be turned on and off at the touch of a button. It also enables control of all the loudspeakers and the content fed to them, and the control system also manages signal delay to keep the pictures and sound in sync.
The museum’s development director Kaisa Laitinen is delighted with the results. “Through spectacular visuals and a strong world of sound, the museum visitor's experience is better than ever,” she declares. “Studiotec and Granlund have done a great job in bringing our vision to life. The use of the latest technology enables visitors to share in the adrenalin, the triumphs and the disappointments along with all the emotions and feelings that sport brings. I’m very proud of what we have achieved and I’m excited to share it with the public.”
DocumentsOperating Manual 8030C Quick Setup Guide 8030C Classic Active Monitoring Series Catalogue 2018 Genelec 8030C Operating Manual - Chinese
DownloadsLine Drawings (PDF) 8030C Line Drawings (DWG) 8030C 8030C - Simulation File (CLF) 8030C - Simulation File (EASE3) 8030C - Simulation File (EASE4)
What types of damping materials are used inside Genelec monitor and subwoofer products? Are the materials safe to use?
Damping Materials Used in Our Monitors
Genelec products use various damping materials such as glass fiber wool, linen fiber wool, and polyester fiber based material (PES). The tables presented below provide a detailed listing of our monitor models and the type of damping material used in each model.
During operation, the air moving in and out of the monitor loudspeaker or subwoofer bass reflex openings does not emit significant amounts of fiber particle dust. The PES wool as material does not emit dust. The linen wool, and glass fiber wool can emit minimum amounts of dust during very high sound level operation. This fiber dust is not hazardous to health.
|SAM™ Studio Monitors||Damping material type|
|SAM™ Studio Subwoofers||Damping material type|
|8000 Series Studio Monitors||Damping material type|
|1000 Series Studio Monitors||Damping material type|
|M Series Studio Monitors||Damping material type|
|7000 Series Studio Subwoofers||Damping material type|
|G Series Active Speakers||Damping material type|
|F Series Active Subwoofers||Damping material type|
|Home Theater Speaker Series||Damping material type|
|Home Theater Subwoofer Series||Damping material type|
|4000 Series Installation Speakers||Damping material type|
|Architectural Speaker Series||Damping material type|
