8320A SAM™ Studio Monitor

Compact enough to fit into the tightest of spaces - yet intelligent enough to adapt to your recording environment - the 8320A is your entry point into the world of Smart Active Monitoring.

Active Crossovers

Directivity Control Waveguide (DCW™) Technology


SPL

100 dB

Frequency Response

55 Hz - 23 kHz (-6dB)

Dimensions

H 242 x W 151 x D 142 mm, with Iso-Pod™ (view in inches)

Transparent and truthful

The 8320A provides transparent and truthful reproduction, and with its wide uncoloured sweet spot you are always in a position to make accurate, reliable mix decisions. The recycled aluminium design of it rear-ported enclosure not only provides staggering LF extension from such a compact unit, its curved form and integrated waveguide guarantees precise, detailed performance both on and off axis.

Compact but clever

As a Smart Active Monitor, the 8320A integrates closely with our GLM software via which it can be configured and calibrated for your listening environment, compensating for detrimental room influences to create a truly optimised monitoring solution from mono to immersive. So whether you work in challenging acoustic spaces or need a mobile solution that can quickly adapt to different rooms, the 8320A is your compact but clever monitoring companion.

Key Technologies

Active Crossovers

Directivity Control Waveguide (DCW™) Technology

Intelligent Signal Sensing (ISS™) Technology

Iso-Pod™ Stand

Minimum Diffraction Enclosure (MDE™) Technology

Optimized Amplifiers

Protection Circuitry

Reflex Port Design

Smart Active Monitor (SAM™) Systems

Versatile Mountings

Genelec

8320A SAM™ Studio Monitor Dark Grey

8320A SAM™ Studio Monitor White

8320A SAM™ Studio Monitor Black

Package contains:

1 x 8320A monitor
1 x mains cable 1,8 m
1 x RJ45 cable 5 m
1 x user manual

Color options:

Technical Specifications

SPL

100 dB

Frequency Response

55 Hz - 23 kHz (-6dB)

Accuracy of Frequency Response

± 1.5 dB (66 Hz - 20 kHz)

Driver Dimensions

105 mm Bass + 19 mm Treble

Amplifier Power

50W Bass (Class D) + 50W Treble (Class D)

Dimensions

H 242 x W 151 x D 142 mm, with Iso-Pod™ (view in inches)

Weight

3.2 kg / 7.1 lb

Connections

1 x XLR Analog Input

2 x RJ45 Control


Featured Showcase

What is GLM (Genelec Loudspeaker Manager)?

What is SAM technology? How will it benefit me? Episode 8 | One Minute Masterclass Season 2

How GLM™ (Genelec Loudspeaker Manager) Software Works

Demonstrating the SAM™ Systems with 8320A, 8330A, 7350A and GLM™ 2.0 Software


Find Your Dealer

Type in your city to find your nearest Genelec dealer

Documentation

FAQ

There are several improvements in the new 83xx products. The capability to adapt to the room acoustics has been improved greatly, and, for example, 8320 and 8330 products provide four to five times higher number of tools for room response compensation compared to the 82xx products. The delay alignment capability has been expanded from about 80 ms to about 200 ms in 83xx. 83xx have been time-equalized internally to have a constant input-to-output delay above 400 Hz. 83xx products can level align by 60 dB.

All 83xx and 73xx products support distributed bass management, enabling the audio signal to be passed unmodified from the source and through the subwoofer into the monitors. 73xx subwoofers support a multichannel analogue audio signal and stereo AES/EBU digital audio signal.
