Smart Active 2-Way Monitors

Genelec Smart Active 2-Ways work closely with our GLM calibration software to create a reference monitoring system that is optimised for your acoustic environment. At last, you’ll produce mixes that translate consistently to other rooms and systems.

Smart Active 2-Way Monitors

8320A

SAM™ Studio Monitor

Compact enough to fit into the tightest of spaces - yet intelligent enough to adapt to your recording environment - the 8320A is your entry point into the world of Smart Active Monitoring.


SPL

100 dB

Amplifier Power

50 W Bass (Class D) + 50 W Treble (Class D)

Frequency Response

55 Hz - 23 kHz (-6 dB)

Accuracy of Frequency Response

± 1.5 dB (66 Hz - 20 kHz)

Driver Dimensions

105mm Bass + 19mm Treble (view in inches)

Dimensions

H 242 x W 151 x D 142 mm, with Iso-Pod™ (view in inches)

Weight

3.2 kg / 7.1 lb

Connections

1 x XLR Analog Input

2 x RJ45 Control

Genelec 8330A SAM Studio Monitor

8330A

SAM™ Studio Monitor

Combining precision, adaptability and a small footprint, the 8330A offers colour-free performance and powerful room compensation features.


SPL

104 dB

Amplifier Power

50 W Bass (Class D) + 50 W Treble (Class D)

Frequency Response

45 Hz - 23 kHz (-6 dB)

Accuracy of Frequency Response

± 1.5 dB (58 Hz - 20 kHz)

Driver Dimensions

130mm Bass + 19mm Treble (view in inches)

Dimensions

H 299 x W 189 x D 178 mm, with Iso-Pod™ (view in inches)

Weight

5.5 kg / 12.1 lb

Connections

1 x XLR Analog Input

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control

Genelec 8340A SAM Studio Monitor

8340A

SAM™ Studio Monitor

Elevate the accuracy of your audio monitoring to a new level with the precision and adaptability of the 8340A Smart Active Monitor.


SPL

110 dB

Amplifier Power

150 W Bass (Class D) + 150 W Treble (Class D)

Frequency Response

38 Hz - 22 kHz (-6 dB)

Accuracy of Frequency Response

± 1.5 dB (45 Hz - 20 kHz)

Driver Dimensions

165mm Bass + 19mm Treble (view in inches)

Dimensions

H 365 x W 237 x D 223 mm, with Iso-Pod™ (view in inches)

Weight

8.4 kg / 18.5 lb

Connections

1 x XLR Analog Input

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control

Genelec 8350A SAM Studio Monitor

8350A

SAM™ Studio Monitor

All the intelligence of Smart Active Monitoring in an extremely potent nearfield monitor. Introducing the Genelec 8350A.


SPL

112 dB

Amplifier Power

200 W Bass (Class D) + 150 W Treble (Class D)

Frequency Response

33 Hz - 22 kHz (-6 dB)

Accuracy of Frequency Response

± 1.5 dB (38 Hz - 20 kHz)

Driver Dimensions

205mm Bass + 25mm Treble (view in inches)

Dimensions

H 452 x W 286 x D 278 mm, with Iso-Pod™ (view in inches)

Weight

12.8 kg / 28.2 lb

Connections

1 x XLR Analog Input

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control

Genelec 1032C SAM Studio Monitor

1032C

SAM™ Studio Monitor

The 1032C is a high-SPL nearfield monitor that fuses the much-loved soffit-mountable styling of the iconic 1000 series with our latest Smart Active Monitoring technology.


SPL

114 dB

Amplifier Power

250 W Bass (Class D) + 150 W Treble (Class D)

Frequency Response

33 Hz - 23 kHz (-6 dB)

Accuracy of Frequency Response

± 2.5 dB (40 Hz - 20 kHz)

Driver Dimensions

250mm Bass + 25mm Treble (view in inches)

Dimensions

H 495 x W 320 x D 290 mm, (view in inches)

Weight

17 kg / 37.5 lb

Connections

1 x XLR Analog Input

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control
