8331A

SAM™ Studio Monitor

Incredible three-way point source monitor with the footprint of a compact two-way. When space and precision is of the essence, nothing even comes close.

Smart Active Monitoring (SAM™) and GLM™ calibration technology

Minimum Diffraction Coaxial (MDC™) Driver Technology


SPL

104 dB

Frequency Response

45 Hz - 37 kHz (-6 dB)

Dimensions

H 305 x W 189 x D 212 mm, with Iso-Pod™ (view in inches)

Work faster, for longer

For applications calling for extraordinary imaging, extended frequency response, short to medium listening distance or long, fatigue-free working hours, The Ones are in an elite league of their own. They promote faster and more consistent decision making, and they also extend listening time, because unnatural imaging - a main contributor to listener fatigue - is minimised.

Mixes that translate

The smallest in The Ones series, the 8331A is perfect for small rooms or ultra-nearfield applications, and offers an outstanding solution where none existed before. And in conjunction with our GLM calibration software, the 8331A will compensate for detrimental room acoustics and distance delay, regardless of whether you work in mono, stereo or immersive formats. So now you can deliver mixes that translate beautifully - every time.

Genelec

8331A SAM™ Studio Monitor Dark Grey

8331A SAM™ Studio Monitor White

8331A SAM™ Studio Monitor Black

8331A SAM™ Studio Monitor RAW

Color options:
Package contains:

1 x 8331A monitor
1 x mains cable 1,8 m
1 x RJ45 cable 5 m
1 x operating manual
1 x The Ones brochure

Warranty:
2 years parts-and-labour (extended to 5 years with free registration).

GLM Calibration:
Requires free GLM software and either our 9320A SAM™ Reference Controller or GLM Calibration Kit device (both sold separately) for calibration.

Genelec

8331A SAM™ Studio Monitor Dark Grey

8331A SAM™ Studio Monitor White

8331A SAM™ Studio Monitor Black

8331A SAM™ Studio Monitor RAW

Color options:

Technical Specifications

SPL

104 dB

Amplifier Power

72 W Bass (Class D) + 36 W Midrange (Class D) + 36 W Treble (Class D)

Frequency Response

45 Hz - 37 kHz ("-6 dB")

Accuracy of Frequency Response

± 1.5 dB (58 Hz - 20 kHz)

Driver Dimensions

2 x H 65 x W 130 mm Bass + 90 mm Midrange + 19 mm Treble (view in inches)

Dimensions

H 305 x W 189 x D 212 mm, with Iso-Pod™ (view in inches)

Weight

6.7 kg / 14.8 lb

Connections

1 x XLR Analog Input

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control


Key Technologies

Smart Active Monitoring (SAM™) and GLM™ calibration technology

Minimum Diffraction Coaxial (MDC™) Driver Technology

Acoustically Concealed Woofers (ACW™) Technology

Directivity Control Waveguide (DCW™) Technology

Minimum Diffraction Enclosure (MDE™) Technology

Reflex Port Design

Protection Circuitry

Intelligent Signal Sensing (ISS™) Technology

Optimised Amplifiers

Active Crossovers

Iso-Pod™ Stand

Versatile Mountings


References

Audioguy Studios: Recording immersive music with Genelec monitors

Electronic Music Composer Richard Devine Studio Interview | Genelec 8331

One on One with ARET Engineering | Genelec 8331| Interview

Review: Genelec The Ones

We are The Ones

Developing The Ones

Using GLM | Walkthrough

Using GLM | The foundations

Using GLM | Controlling GLM with MIDI

Using GLM | GRADE Room Acoustic Report

Using GLM | Calibration Group IDs

Using GLM | Accounts and product registration

Using GLM | The technical details
